Evenlode Ground Data System
The Evenlode Ground Data System is part of the Evenlode Series and complements the Evenlode Airborne Data Links.
Equipment that is available in the Evenlode Ground Data Terminal system:
- Rack Transceiver
- Rack Dual Receiver or X-Versity Receiver
- Antenna Control Unit (MSA5, 6, 9 and Steerable)
- Mast Mounted Power Amplifier and Power Supply
- Rack ASI/IP Decoder (Dual and Single)
- Mains or Battery Power Supplies
- Range of antenna solutions from omnidirectional to high gain tracking dish antennas
Product Description
The Evenlode Ground Data System is a modular system that complements the Evenlode Series of Airborne Data Terminals. The GDS is based on a half width 19” rack system that provides ground based equipment from test transmitters and receivers through to long range bidirectional tracking antenna fixed base stations.
The Evenlode GDS provides a suite of antenna options ranging from covert omnidirectional antennas to tracking antennas that can achieve ranges in excess of 200 nautical miles.
Enterprise Control Systems Ltd (ECS) provides the complete ‘turnkey’ ground solution including: antennas, cabling, lightning protection, receivers, transmitters, power supplies, test equipment, installation and training.
Technical Specifications
IF Input Frequency
500-800 MHz
IF Output Frequency
400 MHz
Link Data Rate
1 – 20 Mbps
Digital Video Output
DVI (HDMI type A connector)
Digital Video Input
SD-SDI
Control Port
RS232 4-way Lemo
GPS Data
RS232 9-way D-Type Female
Telemetry Data Port
RS232/485 9-way D-Type Female
Modulation
DVB-T COFDM
Modulation Type
QPSK, 16QAM
Video Formats
576i – 720×526 @25fps (PAL)
480i – 720×480 @30fps (NTSC)
720p – 1280×720 @50/60fps
1080i – 1920×1080 @25/30fps
Video Compression
AVC
H.264
MPEG-4
Data Interfaces
100/10BASE-T ethernet and ASI
Encryption/Decryption
AES 256 (subject to export license approval) or substitution cipher
ASI Input/Output
MPEG-2 TS ISO/IEC 13818-1 ETSI TR 101 891
