8105 HF Multicoupler

Outstanding performance is assured

  • High-performance, cost-effective
  • Small land area
  • High dynamic range: 5 dB NF, +40 dBm IP3
  • Phase and amplitude matching: ± 2˚, ± 0.5 dB
  • Input overload protection and alert
  • Rugged modular design: 1–8 plug-in modules per chassis

Product Description

The versatile Model 8105 is an HF multicoupler that provides multiple phase and amplitude-matched outputs from a single or multiple RF antennas operating in the 2 to 30 MHz range. It consists of a standard 4U (19-in) rack-mount chassis holding one to eight plug-in multicoupler modules. Each module is a 1-IN x M-OUT, where M = 1, 2, 4, or 8. The full complement of eight modules off ers a maximum of 8 inputs and 64 outputs, which can be configured in many ways, including cascading modules to provide up to 57 outputs from a single input. This flexibility enables the 8105 to provide highly cost effective RF distribution to multiple receivers from multiple-element antenna arrays. It is also ideal for distributing reference signals such as 5 or 10 MHz frequency standards.
