Cutting-Edge EMC Test Facility
Delve into ECS’s custom-built semi-anechoic chamber designed for in-house product development and pre-compliance testing—an invaluable resource for external organizations. This chamber, featuring ferrite tiles and hybrid RF absorbers, ensures precise testing environments.
Key Chamber Specifications:
• Dimensions: L = 30.9 m, W = 7.24 m, H = 3.98 m, with a 24m range for vehicles • RF hybrid absorbers, 0.3m long, partially applied to walls & ceiling • Vehicle Access: 3.33 m high x 4 m wide • Exhaust Extraction: 2,000 m3 / hour • L1 GPS Repeater • Turntable: 5 m diameter, accommodating a 20-tonne max load, with 1° increments and +/-0.2° accuracy • Screening Efficiency: Complies with IEEE-299/MIL-STD-285/EN50147-1 (10 kHz – 18 GHz) • Normalised Attenuation: As per ANSI C63.4 (80 MHz to 18 GHz) • Test System Noise Floor: Adheres to DEF-STAN 59-411, DRE03 Class A standards
Versatile Testing Capabilities:
From radiated emissions (9 kHz to 18 GHz) to conducted emissions (AC & DC, 9 kHz to 200 MHz), ECS’s capabilities span a broad spectrum:
- ESD Testing: Contact and Air Discharge up to 30 KV
- Product Safety Assessments, including Safe Approach Measurements
- Vehicle and Occupant Safety Checks
- Vehicle Mounted Antenna Testing
- RF Inhibition Testing
- Complex Antenna System Radiation Patterns
- Antenna Radiation Patterns from 400 MHz to 18 GHz
- Comprehensive EMC and RF test equipment
- Three Phase @ 32 Amps and varied DC supplies
- Single-phase AC supply up to 400 Hz
- Custom control software for automated test profiles
- Strategic rural location
- Self-contained EMC facility, independent of ECS
- Quick availability and flexible, responsive service
- ISO 9001 and DAOS certified
Comprehensive Support:
Benefit from the expertise of an EMC Technician managing operations, supported by engineering resources and EMC Experts offering compliance design assistance. ECS specializes in Aerospace, Automotive, and Military test Standards.
For further inquiries or to book our services, please contact us.
